The American boat manufacturer Four Winns presents the TH38, the latest model in its TH catamaran series. The boat combines the advantages of a twin-hull design with extensive living areas and is aimed at boaters planning both day trips and longer stays on board.
Double hull for more stability
The CE certification of the new Four Winns in categories B for up to 8 people and C for up to 14 people emphasises the versatility of the boat for different sailing areas. The twin-hull design not only offers stability advantages, but also creates generous space with over 15 square metres of deck area. The hull shape also promises smoother sailing characteristics in different weather conditions.
Flexible cockpit layout
A key feature of the TH38 is its convertible deck layout. The boat has two sliding L-shaped benches with storage space underneath, which can be converted into a spacious sunbathing area. There is a choice of two windscreen options for the helm position: a raised full windscreen for maximum weather protection or a flatter, sportier version for a more open driving experience.
The central galley forms the heart of the outdoor area and is equipped with a sink, waste bin, 65-litre refrigerator and, on request, a single electric hob. Its central position makes it practical to use during your stay on deck. Two cockpit tables in the stern area with integrated cup holders complete the equipment.
Living comfort below deck
Below deck, the TH38 offers plenty of living space for a boat of this category. Two separate cabins with a total of four berths allow for trips lasting several days. Particular attention has been paid to practical details: Hull windows provide natural light, USB ports and 230 V sockets offer connection options for electronic devices. The wet room has an electric marine toilet, a separate shower and two 65-litre faeces tanks.
The catamaran can be equipped with outboard engines with a maximum total output of 700 hp (515 kW). With a fuel tank of 930 litres, the boat is equipped for longer trips. The fresh water tank holds 50 litres and is supplemented by a 230 V water heater. The standard equipment includes a Seanapps system for remote monitoring of the boat, a self-draining cockpit, electric and manual bilge pumps and six retractable stainless steel cleats. The bathing platform at the stern and a central platform with ladder facilitate access to the water.
Technical data:
- Length over everything: 11,82 m
- Torso length: 11,42 m
- Width: 4,47 m
- CE certification: B8/C14
- Fuel tank: 930 l
- Fresh water tank: 50 l
- Draught min: 0,60 m
- Max. draught: 0,98 m
- Displacement (with motor): 7,419 kg
- Max. motor power: 700 hp/cv (515 kW)
- Cabins: 2
- Sleeping places: 4
- Holding tanks: 2 × 65 l
- Info: https://www.fourwinns.com/
